Front Weld-On Hanger Bracket, 1000 - 3500 lbs., Dexter 86274

Dexter Front Weld-On Hanger Bracket, part 86274

Solid steel stock font weld-on hanger for use on 1-3/4" slipper and double eye springs that are mounted on 1,000 lbs to 3,500 lbs capacity rated medium duty axles.  Pre-drilled for 9/16 inch bolt.

Specs:

• 4-gage steel
• Flange-to-flange width: 2-1/4"
• Inside bolt hole-to-surface clearance: 1-3/8"
• Front location for 1000 - 3500 lbs. rated axles
• Sold each

Dimensions:

• A: 2-1/4 inches
• B: 1-3/8 inches
• C: 1-1/2 inches

Dexter has been a leading manufacturer of trailer axles and trailer brakes for over 50 years for the utility trailer, recreation vehicle, heavy duty, manufactured housing, agricultural, marine, and specialty trailer markets.
