WARN AXON 55 Winch, 5,500 lb Capacity, Steel Rope
The WARN AXON 55 Winch, 5,500 lb Capacity, Steel Rope is built for owners of the biggest UTVs who need 5,500 lb of pulling capacity. It pairs a 5,500 lb single-line rating with 50 ft of steel rope and IP68 waterproof sealing, so it keeps pulling in mud, water and dust.
Key Features
- 5,500 lb rated line pull (single line)
- 50 ft x 1/4 in steel rope
- Motactor design combines the motor and digital contactor in one unit
- Digital control provides load and temperature feedback
- All-metal 3-stage planetary gear train
- Clutch design based on WARN 4WD hub lock know-how, with free spooling
- IP68 waterproof sealing keeps water and dirt out
- Roller fairlead and black hook
- Rockerbar digital control switch
- HUB Wireless Receiver included
Specifications
- Manufacturer Part Number: 101155
- Rated line pull: 5,500 lb (single line)
- Rope: 50 ft x 0.25 in (1/4 in) steel
- Motor: Motactor (motor + digital contactor) with 12V DC permanent magnet
- Brake: Load-holding brake, automatic
- Sealing: IP68 waterproof
- Fairlead: Roller
- Control: Rockerbar digital control switch
- Mounting bolt pattern: 3 in x 6.59 in
- Winch dimensions: 15.0 in L x 4.6 in W x 4.8 in H
- Finish: Satin black powder-coated finish, stainless steel fasteners
- Includes: 50 ft x 1/4 in steel rope; Roller fairlead; Rockerbar digital control switch; HUB Wireless Receiver
Compatibility
Built for the biggest UTVs. Check the 3 in x 6.59 in mounting bolt pattern against your winch mount or bumper before ordering, and confirm the winch dimensions (15.0 in L x 4.6 in W x 4.8 in H) fit your mounting space.
Important Purchase Notes
This winch does not include a vehicle mounting kit. A vehicle-specific winch mount or winch-compatible bumper matched to the 3 in x 6.59 in mounting pattern is required for installation and is sold separately.
Frequently Asked Questions
What vehicles is this winch made for?
It is built for the biggest UTVs, with a 5,500 lb single-line rating.
What rope does it come with?
It includes 50 ft x 0.25 in (1/4 in) steel rope with a roller fairlead.
How is the winch controlled?
Control is by rockerbar digital control switch. The HUB Wireless Receiver is included.
