Trailer Hub Kits

Complete 4 Hole Trailer Hub Kit. Fits 1" axle spindle, 1000 lbs. capacity, demountable. This high speed trailer hub is ideal for highway rated trailers. The trailer hub assembly includes: nuts, bolts, 2 bearings, 2 bearing cups, 1 grease seal and a dust cap. Specs: bolt size: 4 stud, inner bearing size: 1" part LM44643, outer bearing size:  1"part LM44643, hub length: 4-1/8", distance between races: 2-7/16", hub capacity: 1000 lbs.

Shipshape Trailer Parts provides these convenient hub replacement kits for many trailer applications. Painted cast iron studded hub for 1" spindle. Bolt pattern: 4 x 4". Flange Outside Diameter: 5-9/16". Rated 1250 lbs. Hub Inside Diameter: 1.98". Maximum recommended wheel size: 12". Sold each: Includes hub, bearings, seals, dust cap, grease and lug nuts

Complete 4 Hole Trailer Hub Kit. Fits 1-1/16" axle spindle, 1150 lbs. capacity, demountable. This high speed trailer hub is ideal for highway rated trailers. The trailer hub assembly includes: nuts, bolts, 2 bearings, 2 bearing cups, 1 grease seal and a dust cap. Specs: bolt size: 4 stud, inner bearing size: 1-1/16" part LM44649, outer bearing size: 1-1/16" part LM44649, hub length: 4-1/8", distance between races: 2-7/16", hub capacity: 1150 lbs.

Shipshape Trailer Parts provides these convenient hub replacement kits for many trailer applications. Painted cast iron studded hub for 1-1/16" spindle. Bolt pattern: 4 x 4". Flange Outside Diameter: 5-9/16". Rated 1350 lbs. Hub Inside Diameter: 1.98". Maximum recommended wheel size: 12". Sold each: -Includes hub, bearings, seals, dust cap, grease and lug nuts

Complete 5 Hole Trailer Hub Kit. Fits 1" axle spindle, 1000 lbs. capacity, demountable. This high speed trailer hub is ideal for highway rated trailers. The trailer hub assembly includes: nuts, bolts, 2 bearings, 2 bearing cups, 1 grease seal and a dust cap. Specs: bolt size: 5 stud, inner bearing size: 1" part LM44643, outer bearing size: 1" part LM44643, hub length: 4-1/8", distance between races: 2-7/16", hub capacity: 1000 lbs.

Shipshape Trailer Parts provides these convenient hub replacement kits for many trailer applications. Painted cast iron studded hub for 1" spindle. Bolt pattern: 5 x 4-1/2". Flange Outside Diameter: 5-9/16". Rated 1250 lbs. Hub Inside Diameter: 1.98". Maximum recommended wheel size: 12". Sold each: -Includes hub, bearings, seals, dust cap, grease and lug nuts

Complete 5 Hole Trailer Hub Kit. Fits 1" axle spindle, 700 lbs. capacity, demountable. This high speed trailer hub is ideal for highway rated trailers. The trailer hub assembly includes: nuts, bolts, 2 bearings, 2 bearing cups, 1 grease seal and a dust cap. Specs: bolt size: 5 stud, inner bearing size: 1" part LM44643, outer bearing size: 1" part LM44643, hub length: 3-1/2", distance between races: 1-11/16", hub capacity: 700 lbs.

Complete 5 Hole Trailer Hub Kit. Fits 1-1/16" axle spindle, 1150 lbs. capacity, demountable. This high speed trailer hub is ideal for highway rated trailers. The trailer hub assembly includes: nuts, bolts, 2 bearings, 2 bearing cups, 1 grease seal and a dust cap. Specs: bolt size: 5 stud, inner bearing size: 1-1/16" LM44649, outer bearing size: 1-1/16" LM44649, hub length: 4-1/8", distance between races: 2-7/16", hub capacity: 1150 lbs.

Complete 5 Hole Trailer Hub Kit. Fits 1-1/4" axle spindle, 1250 lbs. capacity, demountable. This high speed trailer hub is ideal for highway rated trailers. The trailer hub assembly includes: nuts, bolts, 2 bearings, 2 bearing cups, 1 grease seal and a dust cap. Specs: bolt size: 5 stud, inner bearing size: 1-1/4" part LM67048, outer bearing size: 1-1/4" part LM67048, hub length: 4-3/16", distance between races: 2-3/16", hub capacity: 1250 lbs.

Complete 5 Hole Trailer Hub Kit. Fits 1-3/8" to 1-1/16" axle spindle, 1750 lbs. capacity, demountable. This high speed trailer hub is ideal for highway rated trailers. The trailer hub assembly includes: nuts, bolts, 2 bearings, 2 bearing cups, 1 grease seal and a dust cap. Specs: bolt size: 5 stud, inner bearing size: 1-3/8" part LM68149, outer bearing size: 1-1/16" part LM44649, hub length: 4-1/4", distance between races: 2-7/16", hub capacity: 1750 lbs.

Pre-greased, marine-grade hub is built for trailer idler axles. Fits 2.5K axles with BT8 spindles. Inner bearing and race, outer bearing and race, grease seal, cap, lug nuts, and cotter pin included. For 8" to 12" wheels. Includes galvanized hub fully assembled with pre-greased bearings, dust cap, cotter pin and lug nuts.

Complete 5 Hole Trailer Hub Kit. Fits 1-1/16" axle spindle. This high speed trailer hub is ideal for highway rated trailers. The trailer hub assembly includes: nuts, bolts, 2 bearings, 2 bearing cups, 1 grease seal and a dust cap. Specs: bolt size: 5 stud, inner bearing size: 1-1/16" part LM44649, outer bearing size:  1-1/16"part LM44649, hub length: 4-1/8", distance between races: 2-7/16".

Complete 4 Hole Trailer Hub Kit. Fits 1-1/16" axle spindle. This high speed trailer hub is ideal for highway rated trailers. The trailer hub assembly includes: nuts, bolts, 2 bearings, 2 bearing cups, 1 grease seal and a dust cap. Specs: bolt size: 4 stud, inner bearing size: 1-1/16" part LM44649, outer bearing size:  1-1/16"part LM44649, hub length: 4-1/8", distance between races: 2-7/16".
